| 欧州RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8541.49.80.00 |
| Automotive | No |
| PPAP | No |
| Output Type | DC |
| Input Type | DC |
| Output Device | Linear Photovoltaic |
| Number of Channels per Chip | 1 |
| Minimum Isolation Voltage (Vrms) | 5300 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Operating Temperature (°C) | 100 |
| Maximum Forward Voltage (V) | 1.5 |
| Standard | BSI|cUL|FIMKO|UL |
| Maximum Power Dissipation (mW) | 210 |
| Maximum Reverse Voltage (V) | 5 |
| Typical Forward Voltage (V) | 1.25 |
| Maximum Forward Current (mA) | 60 |
| Typical Rise Time (us) | 1.75 |
| Typical Fall Time (us) | 1.75 |
| Mounting | Through Hole |
| Package Height | 3.81(Max) |
| Package Width | 6.6(Max) |
| Package Length | 10.16(Max) |
| PCB changed | 8 |
| Supplier Package | PDIP-8A |
| Pin Count | 8 |
| Lead Shape | Through Hole |
