TPS659121EVM-081, Evaluation Module using TPS659121 a power management unit (PMU) for Processor Power
Reference Design using part TPS659121YFF by Texas Instruments
1 / 3
For End Products
- Smart Phone
- Wireless Data Access Card
Description
- TPS659121EVM-081, Evaluation Module (EVM) is designed to facilitate evaluation of the power management integrated circuit. It also contains 10 LDO regulators for external usage which can be supplied from either a battery or a pre-regulated supply. Power-up/power-down controller is configurable and can support any power-up/power-down sequences (OTP based). The TPS659121 integrates a 32 kHz RC Oscillator to sequence all resources during Power up / down
Key Features
-
Conversion TypeDC to DC
-
Input Voltage3 to 5 V
-
TopologyBuck
Featured Parts (1)
| Part Number | Manufacturer | Type | Description | |||
|---|---|---|---|---|---|---|
|
TPS659121YFFR | Texas Instruments | PMIC Solutions | Application Processors 2.7V to 5.5V 81-Pin DSBGA T/R | Buy | |
