TWR-MCF51QM, ColdFire+ MCF51QM Tower System Module based on the MCF51QM128 MCU
使用 NXP Semiconductors 的 MCF51QM128VLH 的参考设计
1 / 9
依据最终产品
- Consumer Electronics
- Industrial
说明
- TWR-MCF51QM, ColdFire+ MCF51QM Tower System Module based on the MCF51QM128 MCU. The TWR-MCF51QM module is a development board for the ColdFire+ MCF51Qx 32-bit MCUs. It is designed to enable rapid prototyping of consumer and Industrial applications requiring ultra-low power and rich peripheral combinations, including 16-bit ADC, hardware encryption, touch sensing and more. The TWR-MCF51QM operates as a standalone debug tool and can also be combined and used as part of the modular Tower System development platform
主要特色
-
Embedded System TypeMCU
-
Family NameColdFire
-
Core ProcessorColdfire V1
-
PlatformTower System
Featured Parts (41)
| 零件编号 | 供应商 | 类别 | 说明 | |||
|---|---|---|---|---|---|---|
|
SN74LVC1G126DRYR | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 1-CH Non-Inverting 3-ST CMOS 6-Pin USON T/R | 买入 | |
|
SN74LVC1G126DBVT | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin SOT-23 T/R | 买入 | |
|
SN74LVC1T45DCKR-P | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin SC-70 | 买入 | |
|
|
SN74LVC1T45DCKT | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin SC-70 T/R | 买入 | |
|
|
SN74LVC1T45DCKRE4 | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin SC-70 T/R | 买入 | |
|
SN74LVC1T45YZPR | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin DSBGA T/R | 买入 | |
|
MIC2026-1YM | Microchip Technology | USB Power Switches | USB Power Switch Dual 5.5V 0.9A 8-Pin SOIC N Tube | 买入 | |
|
MIC5239-1.8YM | Microchip Technology | Linear Regulators | LDO Regulator Pos 1.8V 0.5A 8-Pin SOIC N Tube | 买入 | |
|
SN74LVC1G126DCKR-P | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin SC-70 | 买入 | |
|
|
SN74LVC1G126DCKT | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin SC-70 T/R | 买入 | |
|
SN74LVC1T45DBVRE4 | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin SOT-23 T/R | 买入 | |
|
|
SN74LVC1T45DCKRG4 | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin SC-70 T/R | 买入 | |
