MPC5748G-GW-RDB, MPC5748G Secure Ethernet Gateway Reference Design
NXP Semiconductors の部品 PPC5748GK を使用したリファレンス デザイン
画像
1 / 23
最終製品向け
- Automotive Gateway
説明
- MPC5748G-GW-RDB, Reference Design Board engineered for providing A-sample like Ethernet Gateway ECU, supporting secure Over-the-Air (OTA) management and Functional Safety to help accelerate gateway products development and production. Based on the 32-bit Power Architecture MPC5748G ultra-reliable microcontroller, the MPC5748G-GW-RDB offers up to three e200 cores, Hardware Security Module (HSM), several communication interfaces, and flexible memory options
主な特徴
-
Embedded System TypeMCU
-
Core Processore200
注目のパーツ (14)
| 部品番号 | メーカー | タイプ | 説明 | |||
|---|---|---|---|---|---|---|
|
AUIPS7091GTR | Infineon Technologies AG | Current Limit Switches | Current Limit SW 1-IN 1-OUT 6V to 28V 1.5A Automotive AEC-Q100 8-Pin SOIC N T/R | 買う | |
|
MCP6022-I/SN | Microchip Technology | Operational Amplifiers - Op Amps | Op Amp Dual GP R-R I/O 5.5V 8-Pin SOIC N Tube Automotive AEC-Q100 | 買う | |
|
MC33FS6522LAE | NXP Semiconductors | Specialized Interfaces | High Performance System Basis Chip IC Automotive AEC-Q100 | 買う | |
|
MAX3232CUE+ | Analog Devices | Bus Line Transceivers | Dual Transmitter/Receiver RS-232 16-Pin TSSOP Tube | 買う | |
|
TSX-3225 25.0000MF10P-C | Epson America, Inc | Crystals | Crystal 25MHz ±10ppm (Tol) ±10ppm (Stability) 18pF FUND 40Ohm 4-Pin Mini-CSMD Bulk | 買う | |
|
LM2678S-ADJ/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 8V to 40V Step Down Single-Out 1.2V to 37V 5A 8-Pin(7+Tab) TO-263 Tube | 買う | |
|
ABM3-8.000MHZ-D2Y-T | Abracon | Crystals | Crystal 8MHz ±20ppm (Tol) ±30ppm (Stability) 18pF FUND 140Ohm 2-Pin Mini-CSMD T/R | 買う | |
|
SN74LVC2G08DCTR | Texas Instruments | Logic Gates | AND Gate 2-Element 2-IN CMOS 8-Pin SSOP T/R | 買う | |
|
|
LM2678S-ADJ/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 8V to 40V Step Down Single-Out 1.2V to 37V 5A 8-Pin(7+Tab) TO-263 Tube | 買う | |
|
DP83848CVV /NOPB | Texas Instruments | PHY | PHY 1-CH 10Mbps/100Mbps 3.3V Automotive AEC-Q100 48-Pin LQFP Tray | 買う | |
|
|
DP83848CVV/NOPB | Texas Instruments | PHY | PHY 1-CH 10Mbps/100Mbps 3.3V Automotive AEC-Q100 48-Pin LQFP Tray | 買う | |
|
LD1117S12TR | STMicroelectronics | Linear Regulators | LDO Regulator Pos 1.2V 1.3A 4-Pin(3+Tab) SOT-223 T/R | 買う | |
