DM330017, Buck-Boost Digital Power Starter Kit based on dsPIC33 MCU
使用 Microchip Technology 的 MCP1703-5002E/DB 的参考设计
1 / 6
依据最终产品
- Power Conversion
说明
- DM330017, MPLAB Starter Kit for Digital Power allows the user to easily explore the capabilities and features of the dsPIC33F GS Digital Power Conversion family. It is a digitally controlled power supply board that consists of one independent DC/DC synchronous Buck converter and one independent DC/DC Boost converter. Each power stage includes a MOSFET controlled 5W resistive load
主要特色
-
Conversion TypeDC to DC
-
Input Voltage7 to 11 V
-
Output Voltage3.3|15 V
-
Output Current0.37@15V|2.5@3.3V A
-
Output Power5 W
-
TopologyBuck Boost
