DM163029, Mechatronics Demonstration Kit for the PIC16F914 MCU
Reference Design using part PIC16F914-E/PGXXX by Microchip Technology
1 / 8
For End Products
- Automotive and Transportation
- Battery Management
- Home Appliances
- Lighting
- Medical and Healthcare
- Motor Control
- Security
- Wireless
Description
- DM163029, Mechatronics Demonstration Kit for the PIC16F914 MCU. The PICDEM Mechatronics demonstration board is an easy-to-use mechatronics development and demonstration platform. Mechatronics refers to implementing intelligent control in a mechanical system. Learn how to use PIC microcontrollers to enhance or replace a mechanical design. The demonstration kit takes a hands-on approach to learning about mechatronics. Jumper wires are provided in the kit which allow the developer to experiment with connecting the PIC microcontroller to various components on the board
