TIDA-00609, Self-Booting Audio System Reference Design
Reference Design using part TLV320AIC3262IYZFR by Texas Instruments
1 / 11
For End Products
- AV Receiver
Description
- TIDA-00609, Self-Booting Audio System Reference Design. The purpose of this Design is to provide the designer hardware and software tools that can be used as reference for audio systems. The new revision of the PurePath Console Motherboard (RevF) adds stand-alone, self-booting capabilities to allow making compelling demos with any EVM that is compatible with this platform
Key Features
-
Output TypeStereo
