PMP7115.2, Isolated Flyback for Industrial using TPS40210 w/ input of 12 VDC 17.2V@0.02A
Texas Instruments の部品 TPS40210DGQ を使用したリファレンス デザイン
画像
1 / 3
最終製品向け
- Industrial
説明
- PMP7115.2, Isolated Flyback for Industrial using TPS40210 w/ input of 12 VDC 17.2V@0.02A. PMP7115.2(17.2V@0.02A) reference design is a 13.2W Flyback which uses a TPS40210 and was intended for Industrial applications. It can generate an Isolated 17.2 volt output at 0.02 Amps from an input of 12 Volts DC. This design has multiple outputs
主な特徴
-
Conversion TypeDC to DC
-
Input Voltage12 V
-
Output Voltage17.2 V
-
Output Current0.02 A
-
Output Power0.344 W
-
TopologyFlyback- CCM
