AD9284-250EBZ 8-Bit, 250MSPS ADC for Instrumentation
Diseño de referencia usando la pieza AD9284BCPZ-250 de Analog Devices
이미지
1 / 7
Para productos finales
- Endoscope
- Instrumentation and Measurement
- Oscilloscope
- Software Defined Radio
Descripción
- Evaluating the AD9284 8bit, 250MSPS Analog-to-Digital Converter
Características clave
-
ADC Resolution8 Bit
-
ADC Sampling Rate250M SPS
Piezas destacadas (6)
| Número de pieza | Fabricante | Tipo | Descripción | |||
|---|---|---|---|---|---|---|
|
NC7WZ07P6X | onsemi | Buffers and Line Drivers | Buffer/Driver 2-CH Non-Inverting Open Drain CMOS 6-Pin SC-88 T/R | AÑADIR AL CARRITO | |
|
|
NC7WZ16P6X | onsemi | Buffers and Line Drivers | Buffer 2-CH Non-Inverting CMOS 6-Pin SC-88 T/R | AÑADIR AL CARRITO | |
|
ADP2108AUJZ-1.8-R7 | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.3V to 5.5V Synchronous Step Down Single-Out 1.8V 0.6A 5-Pin TSOT T/R | AÑADIR AL CARRITO | |
|
BNX016-01 | Murata Manufacturing | EMI Filters | EMI Filter LC-Circuit 15A 25VDC PC Pins Thru-Hole Box | AÑADIR AL CARRITO | |
|
|
ADP2108AUJZ-3.3-R7 | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.3V to 5.5V Synchronous Step Down Single-Out 3.3V 0.6A 5-Pin TSOT T/R | AÑADIR AL CARRITO | |
|
AD9284BCPZ-250 | Analog Devices | Analog to Digital Converters - ADCs | 2-Channel Dual ADC Pipelined 250Msps 8-bit LVDS 48-Pin LFCSP EP Tray | AÑADIR AL CARRITO | |
