EVAL-AD7688SDZ, Evaluation Board for AD7688BRMZ 10-Lead MSOP of 16-bit, 500 kSPS PulSAR ADC
Diseño de referencia usando la pieza AD7688BRMZ de Analog Devices
이미지
1 / 11
Para productos finales
- Data Acquisition System
- Portable Instrumentation
- Portable Medical Instrumentation
- Process Control
Descripción
- EVAL-AD7688SDZ, Evaluation Board for AD7688BRMZ 10-Lead MSOP of 16-bit, 500 kSPS PulSAR ADC. The EVAL-AD7683SDZ is a fully featured evaluation kit for the AD7683 ADC. This board operates in Standalone mode or in conjunction with the System Development Platform, EVAL-SDP-CB1Z. When operated with the System Development Platform software is provided enabling the user to perform detailed analysis of the ADC's performance. This software includes the technical note describing the operation and set up of the evaluation board in Standalone operation or when operated with the System Development Platform. When operated in Standalone mode the ADZS-BRKOUT-EX3 break out board is recommended for access to various control pins
Características clave
-
ADC Resolution16 Bit
-
ADC Sampling Rate500K SPS
Piezas destacadas (9)
| Número de pieza | Fabricante | Tipo | Descripción | |||
|---|---|---|---|---|---|---|
|
24LC32A-I/MS | Microchip Technology | EEPROM | EEPROM Serial-I2C 32K-bit 4K x 8 3.3V/5V 8-Pin MSOP Tube | AÑADIR AL CARRITO | |
|
ADA4841-1YRZ-R7 | Analog Devices | Operational Amplifiers - Op Amps | Op Amp Single Low Noise Amplifier R-R O/P ±6V/12V 8-Pin SOIC N T/R | AÑADIR AL CARRITO | |
|
|
ADP3303ARZ-5 | Analog Devices | Linear Regulators | LDO Regulator Pos 5V 0.2A 8-Pin SOIC N Tube | AÑADIR AL CARRITO | |
|
NC7SZ04P5X | onsemi | Inverters and Schmitt Triggers | Inverter 1-Element CMOS 5-Pin SC-88A T/R | AÑADIR AL CARRITO | |
|
NC7SZ08M5X | onsemi | Logic Gates | AND Gate 1-Element 2-IN CMOS 5-Pin SC-74A T/R | AÑADIR AL CARRITO | |
|
|
ADR435BRZ | Analog Devices | Voltage References | V-Ref Precision 5V 30mA 8-Pin SOIC N Tube | AÑADIR AL CARRITO | |
|
|
NC7SZ04M5X | onsemi | Inverters and Schmitt Triggers | Inverter 1-Element CMOS 5-Pin SC-74A T/R | AÑADIR AL CARRITO | |
|
AD8032ARMZ | Analog Devices | Operational Amplifiers - Op Amps | Op Amp Dual High Speed Amplifier R-R I/O ±6V/12V 8-Pin MSOP Tube | AÑADIR AL CARRITO | |
|
AD7688BRMZ | Analog Devices | Analog to Digital Converters - ADCs | 1-Channel Single ADC SAR 500ksps 16-bit Serial 10-Pin MSOP Tube | AÑADIR AL CARRITO | |
