TIDA-00838, Heat Cost Allocator with wM-Bus at 868 MHz Reference Design
Diseño de referencia usando la pieza CC1310F128RGZ de Texas Instruments
이미지
1 / 6
Para productos finales
- Communications Infrastructure
- Gas and Water Meter
- IoT Applications
- Smart Grid
Descripción
- TIDA-00838, Heat Cost Allocator with wM-Bus at 868 MHz Reference Design. The TIDA-00838 reference design implements a heat cost allocator system following the EN834 standard with the two-sensor measurement method. The solution achieves better than 0.5 degrees Celsius accuracy across a range of +20 to +85 degree Celsius. Two analog temperature sensors are available as matched pairs to eliminate the need for calibration during manufacturing and lowering OEM system cost. Wireless MCU offers wM-Bus support for ST and C-modes (Meter device) at 868MHz and controls the two temperature sensors
Características clave
-
Operating Frequency868 MHz
Piezas destacadas (11)
