TIDEP0043, Aconites EtherCAT Master Stack Reference Design
Diseño de referencia usando la pieza AM3359ZCZ de Texas Instruments
이미지
1 / 17
Para productos finales
- Ethernet
- Industrial Gateway - Router
- Industrial Programmable Logic Controllers (PLCs)
- Motion Control
Descripción
- TIDEP0043, Aconites EtherCAT Master Stack Reference Design. The aconites EC-Master EtherCAT Master stack is a highly portable software stack that can be used on various embedded platforms. The EC-Master supports the high performance Sitara MPUs, it provides a sophisticated EtherCAT Master solution which customers can use to implement EtherCAT communication interface boards, EtherCAT based PLC or motion control applications. The EC-Master architectural design does not require additional tasks to be scheduled, thus the full stack functionality is available even on an OS less platform such as Starterware supported on AM335x
Características clave
-
Family NameSitara AM335x
-
Core ProcessorARM Cortex-A8
Piezas destacadas (23)
| Número de pieza | Fabricante | Tipo | Descripción | |||
|---|---|---|---|---|---|---|
|
TPS71718DCKR | Texas Instruments | Linear Regulators | LDO Regulator Pos 1.8V 0.15A 5-Pin SC-70 T/R | AÑADIR AL CARRITO | |
|
TPS65910A3A1RSL-222727801 | Texas Instruments | PMIC Solutions | OMAP3 Power Management 2.7V to 5.5V 48-Pin VQFN EP Tube | AÑADIR AL CARRITO | |
|
SN74CB3Q3306APWR | Texas Instruments | Bus Switches | Bus Switch 2-Element CMOS 2-IN 8-Pin TSSOP T/R | AÑADIR AL CARRITO | |
|
MT41J128M16JT-125:K | Micron Technology | DRAM Chip | DRAM Chip DDR3 SDRAM 2Gbit 128Mx16 1.5V 96-Pin FBGA Tray | AÑADIR AL CARRITO | |
|
|
MT41J128M16JT-125:K | Micron Technology | DRAM Chip | DRAM Chip DDR3 SDRAM 2Gbit 128Mx16 1.5V 96-Pin FBGA Tray | AÑADIR AL CARRITO | |
|
SN74LV244APWRG3 | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin TSSOP T/R | AÑADIR AL CARRITO | |
|
PCA9536DGKR | Texas Instruments | GPIO Expanders | I2C/SMBus Interface 100kHz/400kHz 5.5V 8-Pin VSSOP T/R | AÑADIR AL CARRITO | |
|
ABM3-25.000MHZ-B2-T | Abracon | Crystals | Crystal 25MHz ±20ppm (Tol) ±50ppm (Stability) 18pF FUND 30Ohm 2-Pin Mini-CSMD T/R | AÑADIR AL CARRITO | |
|
SN74AUP2G08DCUR | Texas Instruments | Logic Gates | AND Gate 2-Element 2-IN CMOS 8-Pin VSSOP T/R | AÑADIR AL CARRITO | |
|
TPS51200DRCR | Texas Instruments | Special Purpose Voltage Regulators | DDR Memory Termination Regulator 2.375V to 3.5V 10-Pin VSON EP T/R | AÑADIR AL CARRITO | |
|
TPIC2810D | Texas Instruments | LED Drivers | LED Driver 1000uA Supply Current 16-Pin SOIC Tube | AÑADIR AL CARRITO | |
|
SN74CBTLV3257RGYR | Texas Instruments | Bus Switches | Multiplexer/Demultiplexer Bus Switch 1-Element CMOS 8-IN 16-Pin VQFN EP T/R | AÑADIR AL CARRITO | |
