TIDM-DC-DC-BUCK, Digitally Controlled Non-Isolated DC/DC Buck Converter Reference Design
Diseño de referencia usando la pieza LM5109BMAX/NOPB de Texas Instruments
이미지
1 / 5
Para productos finales
- Data Storage Devices
- Industrial Power Supply
- Rectifiers
- Server Power Supply
- Smart Grid
- UPS System
Descripción
- TIDM-DC-DC-BUCK, Digitally Controlled Non-Isolated DC/DC Buck Converter Reference Design. This design implements a non-isolated DC/DC buck converter that is digitally controlled using a C2000 Microcontroller. The main purpose of this design is to evaluate the powerSUITE Digital Power Software tools. The design consists of two separate boards: 1) Digital Power Booster pack and 2) C2000 F28069M LaunchPad or C2000 F28377S LaunchPad
