TPS23753AEVM-001 Evaluation Module for TPS23753A, IEEE 802.3-2005 compliant, powered-device (PD) controller and power supply controller optimized for isolated converter topologies
Texas Instruments の部品 TPS23753APW を使用したリファレンス デザイン
画像
1 / 1
最終製品向け
- IP Phone
- PoE Security Camera
- PoE Wireless Access Point
- Wireless LAN
説明
- TPS23753AEVM-001 allows reference circuitry evaluation of the TPS23753A. It contains input and output power connectors and an array of on-board test points for circuit evaluation. TPS23753AEVM-002 (3.3-V output) can be configured with simple bill of materials (BOM) changes
主な特徴
-
Conversion TypeDC to DC
-
Input Voltage0 to 57 V
-
Output Voltage3.3|5 V
-
Output Current1.2@5V|2@3.3V A
-
Output Power7 W
-
Efficiency80 %
-
TopologyFlyback
注目のパーツ (6)
