10 to 160MHz Clock Buffer AN-746 Application Circuit
Diseño de referencia usando la pieza ADN2812 de Analog Devices
이미지
1 / 1
Para productos finales
- Automatic Test Equipment
- Instrumentation and Measurement
- Wireless
Descripción
- AN-746 - ADN2812 is a continuous rate clock recovery, data-retiming device based on a multi-loop PLL architecture. ADN2812 can automatically lock to any data rate from 10 Mbps to 2.7 Gbps, recover clock, and retime data without programming and without need for an external reference clock as an acquisition aid
Características clave
-
Operating Frequency10 to 160 MHz
Piezas destacadas (2)
| Número de pieza | Fabricante | Tipo | Descripción | |||
|---|---|---|---|---|---|---|
|
ADN2812ACPZ | Analog Devices | Clock and Data Recovery - CDRs | CDR SONET/SDH 3.3V 32-Pin LFCSP EP Tray | AÑADIR AL CARRITO | |
|
|
ADN2812ACPZ-RL7 | Analog Devices | Clock and Data Recovery - CDRs | CDR SONET/SDH 3.3V 32-Pin LFCSP EP T/R | AÑADIR AL CARRITO | |
