ARIS IoT Board, IoT Development Board for the Synergy S7 Microcontroller ideal for BLE and Wi-Fi Applications
Diseño de referencia usando la pieza R7FS7G27H3A01CFC de Arrow Development Tools
이미지
1 / 19
Para productos finales
- Drones
- Gaming and Toys
- Healthcare Monitoring
- Home Automation
- Industrial Sensor
- Internet of Things (IoT)
- Robotics
- Smart Lighting
- Smart Metering
- Wearable Electronics
Descripción
- ARIS IoT Board, ARIS Board is a ready-to-use IoT hardware and software platform that enables you to get your IoT applications up and running quickly by using the Renesas Synergy development framework. It encourages innovation and product differentiation while enabling developers to reduce time-to-market and decreases the total cost of ownership of a product over its lifetime. The ARIS IoT Board is based around the Renesas Synergy S7 MCU with 240 MHz ARM Cortex-M4 core, which has a host of features that equip it for IoT operation. With Bluetooth Low Energy (BLE 4.1/4.2), Wi-Fi b/g/n support and Ethernet 10/100 port, the ARIS IoT Board can communicate with other devices and the cloud
Piezas destacadas (19)
| Número de pieza | Fabricante | Tipo | Descripción | |||
|---|---|---|---|---|---|---|
|
TLV70033DCKR | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 0.2A 5-Pin SC-70 T/R | AÑADIR AL CARRITO | |
|
ADXRS290 | Analog Devices | Gyroscopes | MEMS Dual Axis 18-Pin LGA Tray | AÑADIR AL CARRITO | |
|
MT48LC16M16A2P-6A:G TR | Micron Technology | DRAM Chip | DRAM Chip SDR SDRAM 256Mbit 16Mx16 3.3V 54-Pin TSOP-II T/R | AÑADIR AL CARRITO | |
|
KSZ8091RNACA-TR | Microchip Technology | PHY | PHY 1-CH 10Mbps/100Mbps 3.3V 24-Pin VQFN EP T/R | AÑADIR AL CARRITO | |
|
S25FL512SAGMFI013 | Infineon Technologies AG | Flash | NOR Flash Serial (SPI, Dual SPI, Quad SPI) 3V/3.3V 512M-bit 512M/256M/128M x 1/2-bit/4-bit 14.5ns 16-Pin SOIC W T/R | AÑADIR AL CARRITO | |
|
ABM11-24.000MHZ-B7G-T3 | Abracon | Crystals | Crystal 24MHz ±15ppm (Tol) ±15ppm (Stability) 10pF FUND 100Ohm 4-Pin Ultra Mini-CSMD T/R | AÑADIR AL CARRITO | |
|
LTC3624EMSE-3.3#PBF | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.7V to 17V Synchronous Step Down Single-Out 3.3V 2A 12-Pin MSOP EP Tube | AÑADIR AL CARRITO | |
|
ADXL362BCCZ-RL7 | Analog Devices | Accelerometers | Accelerometer Triple ±2g/±4g/±8g 2V Medical 16-Pin LGA T/R | AÑADIR AL CARRITO | |
|
LTC4360CSC8-1#TRMPBF | Analog Devices | Specialized Power ICs and Modules | Over Voltage Protection Controller 8-Pin SC-70 T/R | AÑADIR AL CARRITO | |
|
AP2141WG-7 | Diodes Incorporated | USB Power Switches | Power Switch Hi Side 1-OUT 0A 0.095Ohm 5-Pin SOT-25 T/R | AÑADIR AL CARRITO | |
|
|
R5F56216BDLD#U0 | Renesas Electronics | Microcontrollers - MCUs | MCU 32-bit RX CISC 256KB Flash 3.3V 85-Pin TFLGA | AÑADIR AL CARRITO | |
|
|
ABM11-25.000MHZ-B7G-T | Abracon | Crystals | Crystal 25MHz ±15ppm (Tol) ±15ppm (Stability) 10pF FUND 100Ohm 4-Pin Ultra Mini-CSMD T/R | AÑADIR AL CARRITO | |
