TIDA-00550, Dual Channel-to-Channel Isolated Universal Analog Input Module for PLC Reference Design
Diseño de referencia usando la pieza ADS1262IPWR de Texas Instruments
이미지
1 / 14
Para productos finales
- Analog I/O Modules
Descripción
- TIDA-00550, Dual Channel-to-Channel Isolated Universal Analog Input Module for PLC Reference Design. The TIDA-00550 dual channel-to-channel isolated universal analog input module reference design for programmable logic controllers combines precision and flexibility. This Design can measure standard input voltages and currents as well as thermocouples, RTD and 4-20mA Loops used in conjunction with sensor transmitters. With only four input terminals, it is suited for applications where smallest real-estate and high versatility and performance is required at the same time
Características clave
-
ADC Number of Channels2
-
DAC Number of Channels2
Piezas destacadas (16)
