ADM00573, Evaluation Board Using MCP3919 ADC for 16-Bit MCUs
Using Part
Vignette
1 / 7
Documents connexes
Pour les produits finaux
- Automotive Applications
- Energy Meter
- Patient Monitoring
- Portable Instrumentation
Description
- ADM00573, ADC Evaluation Board system provides the opportunity to evaluate the performance of the MCP3919 three-channel Analog Front End (AFE). It also provides a development platform for 16-bit microcontroller-based applications, using the existing 100-pin PIC microcontroller Plug-in Module systems that are compatible with the Explorer 16 Evaluation Board (DM240001) and other high pin count PIC-based demo boards. The system comes with a programmed PIC24FJ256GA110 PIM module that communicates with the Energy Management Utility software for data exchange and ADC setup
Caractéristiques principales
-
ADC Resolution16 Bit
-
ADC Sampling Rate57K SPS
-
Number of Channels3CH
Pièces en vedette (11)
