LTC3828EUH Demo Board, Dual Output High Density 17A Step Down DC/DC w/ Tracking, Vin=5V-12
Using Part
Vignette
1 / 1
Documents connexes
Pour les produits finaux
- Industrial
- Processor Power Management
- Telecom Infrastructure
Description
- Demonstration circuit DC884A is a high current density supply featuring the dual-output, 2-phase synchronous buck regulator LTC3828EUH. The input voltage of the demo board is typically from 5V to 12V. The outputs are 2V/17AMAX and 1.5V/17AMAX
Caractéristiques principales
-
Conversion TypeDC to DC
-
Input Voltage5 to 12 V
-
Output Voltage1.5|2 V
-
Output Current17@1.5V|17@2V A
-
Efficiency88.7 %
-
TopologyBuck
