TAS5142DDV6EVM2, evaluation module for the TAS5142 digital amplifier power output stage using the TAS5086 digital audio PWM processor
Progetto di riferimento usando la parte TAS5086DBT di Texas Instruments
Immagine
1 / 6
Documenti associati
Per prodotti finali
- AV Receiver
- DVD Recorder
- Home Theater
Per contattare il Servizio Clienti.
- TAS5142DDV6EVM2 PurePath Digital customer evaluation module demonstrates the integrated circuits TAS5142DDV and TAS5086DBT. The TAS5142DDV is a high performance, integrated stereo digital amplifier power stage designed to drive 4 speakers at up to 100W per channel
Funzioni principali
-
CODEC Resolution32 Bit
Parti in primo piano (11)
| Numero parte | Produttore | Tipo | Per contattare il Servizio Clienti. | |||
|---|---|---|---|---|---|---|
|
TAS5142DDVR | Texas Instruments | Audio Amplifiers | Audio Amp Speaker 1-CH Mono/2-CH Stereo/4-CH Stereo 200W Class-AB 44-Pin HTSSOP EP T/R | AGGIORNA | |
|
TPS76433DBVRG4 | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 0.15A 5-Pin SOT-23 T/R | AGGIORNA | |
|
MC78M12CDTG | onsemi | Linear Regulators | Standard Regulator Pos 12V 0.5A 3-Pin(2+Tab) DPAK Tube | AGGIORNA | |
|
|
TAS5142DDVRG4 | Texas Instruments | Audio Amplifiers | Audio Amp Speaker 1-CH Mono/2-CH Stereo/4-CH Stereo 200W Class-AB 44-Pin HTSSOP EP T/R | AGGIORNA | |
|
|
TPS76433DBVR | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 0.15A 5-Pin SOT-23 T/R | AGGIORNA | |
|
LM2594M-5.0/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 4.5V to 40V Inv/Step Down Single-Out 5V 0.5A 8-Pin SOIC Tube | AGGIORNA | |
|
|
TAS5142DDV | Texas Instruments | Audio Amplifiers | Audio Amp Speaker 1-CH Mono/2-CH Stereo/4-CH Stereo 200W Class-AB 44-Pin HTSSOP EP Tube | AGGIORNA | |
|
|
LM2594M-5.0/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 4.5V to 40V Inv/Step Down Single-Out 5V 0.5A 8-Pin SOIC Tube | AGGIORNA | |
|
TAS5086DBTR | Texas Instruments | Audio Processors | Audio Processor 6-IN 6-OUT 38-Pin TSSOP | AGGIORNA | |
|
|
TAS5086DBTG4 | Texas Instruments | Audio Processors | Audio Processor 6-IN 6-OUT 38-Pin TSSOP | AGGIORNA | |
|
|
TAS5086DBT | Texas Instruments | Audio Processors | Audio Processor 6-IN 6-OUT 38-Pin TSSOP | AGGIORNA | |
