AFE5816EVM, Evaluation Module for AFE5816 16-Channel Analog Front End
Progetto di riferimento usando la parte AFE5816ZAV di Texas Instruments
Immagine
1 / 4
Per prodotti finali
- Data Acquisition System
- Ultrasound Imaging
Per contattare il Servizio Clienti.
- AFE5816EVM, Evaluation Module is a highly integrated Analog Front-End (AFE) solution specifically designed for ultrasound systems in which high performance and small size are required. The AFE5816EVM integrates a complete time-gain-control (TGC) imaging path and a continuous wave Doppler (CWD) path. It also enables users to select one of various power/noise combinations to optimize system performance. Therefore, the AFE5816EVM is a suitable ultrasound analog front end solution not only for high-end systems, but also for portable systems. This EVM requires and connects with the TSW1400EVM for LVDS data capture and evaluation. The TSW1400EVM is purchased separately and requires the HSDCPro software to function
Funzioni principali
-
ADC Resolution14 Bit
-
ADC Sampling Rate80M SPS
-
Number of Channels16CH
Parti in primo piano (17)
