bq25070 Evaluation Module, 1A, Single Cell LiFePO4 Linear Battery Charger with 4.9 V,50 mA LDO
Progetto di riferimento usando la parte BQ25070DQC di Texas Instruments
Immagine
1 / 3
Documenti associati
Per prodotti finali
- Cellular Phone
- Portable Media Player
- Smart Phone
Per contattare il Servizio Clienti.
- User guide describes the bq25070EVM-740 evaluation module (EVM), how to perform a stand-alone evaluation or interface with a host or system. The converter is designed to deliver up to 1 A of continuous current to the battery and/or system. The device has a 4.9 VDC, 50 mA max internal LDO that can be used for USB applications or any other need. The bq25070 is a highly integrated LiFePO4 linear battery charger targeted at space-limited portable applications. It operates from either a USB port or AC Adapter and charges a single-cell LiFePO4 battery with up to 1 A of charge current. The 30 V maximum input voltage rating with 10.5 V input overvoltage protections supports low-cost unregulated adapters
Funzioni principali
-
Battery TypeLithium-Ion
-
Input Voltage5.1 to 5.5 V
-
Output Voltage0 to 3 V
-
Number of Battery Cells1
Parti in primo piano (11)
