PMP4356, 180W RGB LED Drivers for DLP Projector application
Progetto di riferimento usando la parte LM5002MA di Texas Instruments
Immagine
1 / 7
Documenti associati
Per prodotti finali
- Lighting
Per contattare il Servizio Clienti.
- PMP4356, is RGB LED drivers solution which used in high power density DLP projector. LM3434 and power block CSD87350 are used in each rail to provide up to 15A of drive ability. The design demonstrates high efficiency up to 92.5% at full load within the form factor of 80mm/45mm/10.8mm with good dimming performance
Funzioni principali
-
Output Current15 A
-
Output Power180 W
