TIDA-00224, Industrial Ethernet PHY Brick with Fiber-Optic Interface
Progetto di riferimento usando la parte CDCE913PW di Texas Instruments
Immagine
1 / 8
Documenti associati
Per prodotti finali
- Glass Break Detector
- Industrial
- Industrial Automation HMI
- Remote Control
- Smart Electric Meter
Per contattare il Servizio Clienti.
- TIDA-00224, Industrial Ethernet PHY Brick with Fiber-Optic Interface. This reference design demonstrates multimode fiber-optic Ethernet communication. Its intension is to be used in substation equipment communication. Ethernet communication has been proven as an efficient and flexile method for substation standardization and interoperability. This design features a low power, low cost design to meet different bandwidth and different transmission distance needs. End users can quickly apply it to different substation equipment Ethernet communication designs. IEC61000-4-2-Level 3 ESD performance has been tested on this design to comply with IEC specification
Parti in primo piano (6)
| Numero parte | Produttore | Tipo | Per contattare il Servizio Clienti. | |||
|---|---|---|---|---|---|---|
|
CDCLVC1102PW | Texas Instruments | Clock Buffers and Drivers | Clock Fanout Buffer 2-OUT 1-IN 1:2 8-Pin TSSOP Tube | AGGIORNA | |
|
TPS71518DCKR | Texas Instruments | Linear Regulators | LDO Regulator Pos 1.8V 0.05A 5-Pin SC-70 T/R | AGGIORNA | |
|
445I23D25M0000 | CTS Corporation | Crystals | Crystal 25MHz ±20ppm (Tol) ±30ppm (Stability) 18pF FUND 40Ohm 2-Pin SMD T/R | AGGIORNA | |
|
TPS75433QPWP | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 2A 20-Pin HTSSOP EP Tube | AGGIORNA | |
|
|
445I23D25M00000 | CTS Corporation | Crystals | Crystal 25MHz ±20ppm (Tol) ±30ppm (Stability) 18pF FUND 40Ohm 2-Pin SMD T/R | AGGIORNA | |
|
CDCE913PW | Texas Instruments | Clock Generators and Synthesizers | Clock Generator 8MHz to 160MHz-IN 230MHz-OUT 14-Pin TSSOP Tube | AGGIORNA | |
