ADS5484EVM, Evaluation Module Using ADS5484, 16-bit, 170-MSPS Analog-to-Digital Converter with buffered inputs
Progetto di riferimento usando la parte ADS5484IRGC di Texas Instruments
Immagine
1 / 5
Per prodotti finali
- Data Acquisition System
- Measurement Instruments
- Medical Imaging
- Software Defined Radio
- Test Equipment
- Wireless Infrastructure
Per contattare il Servizio Clienti.
- ADS5484EVM, Evaluation Module Using ADS5484, 16-bit, 170-MSPS Analog-to-Digital Converter with buffered inputs. With the supplied logic analyzer breakout board, the ADC LVDS output can be directly captured using either an Agilent E5405A or Tektronix P6980 touchless probe. The ADS5484EVM is also compatible to TSW1400EVM or TSW1405EVM High Speed LVDS evaluation and capture system, allowing samples to be captured and passed to a PC for rapid analysis and evaluation
Funzioni principali
-
ADC Resolution16 Bit
-
ADC Sampling Rate170M SPS
-
Number of Channels1CH
Parti in primo piano (1)
| Numero parte | Produttore | Tipo | Per contattare il Servizio Clienti. | |||
|---|---|---|---|---|---|---|
|
ADS5484IRGCT | Texas Instruments | Analog to Digital Converters - ADCs | 1-Channel Single ADC Pipelined 170Msps 16-bit Parallel 64-Pin VQFN EP T/R | AGGIORNA | |
